S 715 [BS] - FIRE RETARDANT


Exterior doors are exposed to specific extreme loads (warm and dry inside, cold and wet outside) by the weather. DEVENTER Door Seals for exterior doors provide as much slack compensation as possible for a warped rotating part of a door while allowing for pivoting space on the hinge side, and they cannot get ''snagged''.

The use of newly developed self-extinguishing TPE (Thermoplastic Elastomer) makes DEVENTER Weatherseals extremely suitable for smoke and fire resistant constructions. The fire retardant DEVENTER seals have a burning speed of 0mm / min and therefore do not contribute to fire propagation. DEVENTER sealing profiles with the code S, SV and DS also meet the requirements of smoke density according to EN 1634-3. DEVENTER fire retardant profiles have been tested according to the test method EN ISO11925-2 by the Institut für Fenstertechnik Rosenheim and are classified according to standard EN13501-1: 2007. All DEVENTER fire retardant profiles, including the silicone profiles (DS), amply meet the class E bandwidth.

  • Made of high-quality self-extinguishing TPE (Thermo Plastic Elastomer)
  • Rebate height 15 mm
  • Stop clearance 5 mm
  • Groove width 4-5 mm
  • Groove depth 8 mm
  • Packed in cardboard with 1 spool of 180 mtr
  • Also available for rebate 15 mm; S 712 [BS]

Drawings in .pdf format

S 715 [BS].pdf
Archive – 8.9 KB 10 downloads

Drawings in .dwg format

S 715 [BS].dwg
Archive – 25.9 KB 9 downloads
